19" 2U 24 Port Keystone Patch Panel Frame

It is an unloaded rack panel with individual openings for snap-in keystone modules.

The frame provides the rack mounting and port layout; you choose the actual connection modules that go into it.

Flexibility, mainly. A populated panel commits the rack position to one built-in connection system; an unloaded keystone frame lets you choose the modules yourself and change them later.

That can be particularly useful when the rack needs a small menagerie of Ethernet, fibre, USB, HDMI or other compatible keystone connections rather than several separate panels.

No. It is supplied as an empty frame.

The keystone modules are separate, so you can populate only the positions and connection types you actually need.

No. The steel frame has no cable termination of its own.

If you use a punchdown RJ45 keystone, the IDC termination belongs to that module; if you use a female-to-female coupler, there is no punchdown termination at all.

No. Ethernet is only one possibility. Any suitably compatible keystone-format insert can be used, so the frame is not tied to RJ45 networking.

Yes. Populate the ports you need now and add more keystones later. There is no need to fill the panel on day one.

Yes. The frames are intended for standard snap-in keystone modules. The front aperture is 15 × 20mm.

Yes, where the inserts use a compatible keystone format.

That is one of the useful peculiarities of an unloaded panel: a single rack position can hold a small menagerie of Ethernet, fibre, HDMI, USB or other connections instead of insisting that every opening performs the same job.

It can. The clip opening is standard keystone size, but some shielded or unusually bulky modules have wider bodies behind the face of the panel.

If you are using oversized modules side by side, check the physical width before buying a full panel's worth.

Yes. Standard compatible punchdown RJ45 keystones can be fitted to the frame.

Yes. A compatible RJ45 female-to-female keystone coupler can be used instead of a punchdown jack.

Yes. The frame does not care how each keystone makes its connection.

You can have punchdown jacks in some positions and couplers in others, provided the individual modules are physically compatible with the keystone openings.

Yes. The frame itself is category-neutral, so compatible keystones of different network categories can be fitted.

Just remember that each finished cable channel is still governed by the components used in that particular run.

They can be used where the insert is genuinely compatible with the standard keystone opening. The frame is a mechanical carrier rather than an Ethernet-specific device.

Yes. Shielded keystone modules can be fitted if their body fits the panel and the neighbouring positions.

No fixed maximum module depth is specified. The practical limit is the usable space behind the panel once the module, connector or cable bend is taken into account.

Generally yes, where they follow the standard snap-in keystone format.

The one thing worth checking is the body size on unusually wide or deep modules, because the front clip can be standard while the hardware behind it is considerably more ambitious.

No. Blanking keystones are not supplied with the frame.

No. You can leave unused positions empty. Fit separate blanking inserts only if you want the cleaner finished appearance or your installation calls for them.

None of those. The frame itself has no Ethernet category.

Cat5e, Cat6 or Cat6A performance comes from the keystone module, cable and the other components in the completed channel.

No. The frame has no PoE rating of its own. Remote-power capability is determined by the fitted RJ45 keystone and the rest of the cabling channel.

No. The frame provides no shield-bonding or grounding mechanism for the keystone modules.

Not if you need the panel itself to provide a defined bonding path for the keystone screens.

A shielded module can sit in the opening, but the frame does not bond it; for a deliberately screened channel, use hardware designed to maintain that shielding arrangement throughout.

The frame can certainly carry Cat6A keystones, but the useful claim is about the completed channel rather than the sheet of steel holding the modules.

For a Cat6A link, the keystone, cable, far-end termination and patch leads all need to meet the required category.

No. It is a passive mechanical frame. Network performance is determined by the fitted connection modules and the rest of each cabling channel.

You can change the modules without replacing the frame, which is one of the attractions of the design.

Whether that upgrades the actual link depends on everything else in the run — changing a Cat5e keystone does not quietly transform Cat5e cable hidden in the walls into Cat6A.

That depends on the keystone module you fit. Use an RJ45 keystone whose own specification supports the required PoE type and make sure the rest of the channel is suitable as well.

They are inserted from the rear of the panel and clip into the front aperture.

Allow at least 50mm behind the frame as a sensible planning minimum, then check the actual keystone and cable arrangement.

A deep coupler, a stiff patch plug or a tight cable bend can require more space; 50mm is clearance guidance, not a maximum module depth.

Yes. The module can be unclipped again from the front.

You still need enough access behind the panel to deal with the module and whatever cable or connector is attached to it.

Not necessarily. If you can reach behind the panel, a module can be unclipped and changed without removing the complete frame.

If the rack is packed solid behind it, access rather than the panel design becomes the problem.

Usually, yes. Terminating the keystone while you can hold and see it properly is easier than trying to punch it down after it is buried in the panel.

Fit the completed module into the frame once the termination has been checked.

Yes. A coupler normally just clips into the frame and accepts an RJ45 plug at the rear, while a punchdown keystone has to be terminated onto the installation cable first.

The frame accepts either approach; the module decides the work involved.

Yes. Unclip it and move it to another compatible opening, provided the attached cable or lead has enough length to reach the new position.

Do not force it. Move one of the modules to another position, leave a gap, or use a narrower compatible keystone.

The clip fitting being correct does not guarantee two bulky module bodies will coexist happily behind the panel.

Yes. The ports are individually numbered across the keystone frame range.

No. The frame has numbered positions but no separate writable label strip or paper-insert system.

Yes, in principle. The positions are independent, so you can arrange compatible modules to suit the installation.

Just keep an eye on the rear body size if your chosen keystones are unusually wide.

The 8-port and 16-port frames use a single row. The 24-port and 32-port versions use two rows, and the 48-port frame uses three rows.

Yes. There is no requirement to populate every position consecutively.

Leaving a deliberate gap can be a perfectly sensible way to separate a menagerie of network, fibre or AV connections when the numbered ports alone are not enough to make the layout obvious.

Yes. The four 19-inch frames use the standard 19-inch rack format. The 16-port version is 1U, the 24- and 32-port versions are 2U, and the 48-port version is 3U.

No. There is no rear management bar and there are no built-in rear cable-tie hooks on these frames.

If the cable bundle needs support, provide separate rack cable management.

Yes. Four rack screws are supplied with each frame.

The product specification does not currently state the screw thread for the 10-inch version, so I would not rely on an assumed M6 size there.
